LED Retail Signage, Q Series
Q Series indoor LED video wall signage for vivid, premium retail media and enterprise environments.
Overview
The LED Retail Signage, Q Series is onQ's premium indoor LED video wall solution, specifically engineered for demanding retail media networks and enterprise environments. Available in pixel pitches from P2 to P4, this commercial display is optimised to overcome challenging retail lighting conditions while delivering exceptional visual clarity. With its modular design and seamless integration into the onQ CMS, the Q Series empowers businesses to manage dynamic content across multi-site deployments effortlessly.
Key Features
.png)
.png)
Product features
Enthralling Visual Excellence with Indoor LED Displays
The Q Series delivers the visual excellence that enterprise brands demand from their in-store digital signage. High brightness, accurate colour reproduction, and fine pixel pitch combine to produce a commercial display quality that elevates brand presentation and creates an immersive visual environment. This premium LED video wall transforms retail spaces into compelling brand experiences that drive customer engagement.
Optimised for Retail Media Environments
Retail environments present specific lighting challenges, with bright overhead lighting and natural light creating conditions that can wash out standard screens. The Q Series is optimised for these conditions, with brightness levels and contrast ratios calibrated to deliver vivid, legible content in the demanding light environments typical of modern retail media networks.
Modular Design for Flexible Enterprise Configurations
The Q Series modular cabinet design enables flexible configuration to suit any enterprise installation requirement, from single-panel feature displays to large-format LED video walls spanning entire store facades. This modular system allows retail fitouts to be designed around the commercial display, giving designers the freedom to create the exact visual environments they envision for multi-site deployments.
Seamless Integration with onQ CMS
The Q Series integrates flawlessly with the onQ CMS for centralised content management across your entire retail media network. Push promotional content, update pricing, schedule seasonal campaigns, and manage all digital signage from a single enterprise dashboard. Real-time updates enable retailers to respond instantly to competitive activity without requiring physical access to each store.
Versatile Applications for Q Series LED Retail Signage
The Q Series is expertly deployed across fashion and apparel retailers, electronics stores, supermarkets, automotive dealerships, and home furnishing showrooms. It is the ideal commercial display for any enterprise environment where high-impact digital signage is required at a price point that makes multi-site deployment commercially viable and highly effective.
Built for Premium Retail Media Networks
Designed to meet the rigorous demands of modern retail, this indoor LED video wall ensures your promotional content is always displayed with maximum impact. Whether used as a standalone digital signage solution or as part of a comprehensive retail media network, the Q Series delivers reliable, continuous performance for enterprise applications.
Adaptable Video Wall Designs for Indoor Environments
Our modular indoor LED displays offer unparalleled flexibility, allowing you to create adaptable video walls that fit seamlessly into any enterprise space. Unlike traditional commercial displays with fixed aspect ratios, these modular panels let you design unique, large-scale digital signage tailored to your specific architectural requirements and retail media strategies.
Ultimate Customisation for Multi-Site Deployments
Whether you are covering an entire wall, designing a towering vertical display, or wrapping screens around architectural features, this indoor LED video wall provides the creative freedom to achieve a visually impactful setup. Each panel’s unique cabinet size allows for ultimate customisation and easy alignment, supporting both unconventional layouts and traditional aspect ratios.
Specification
- Pixel Pitch (mm): 1.68
- Pixel (dot): 608 × 342
- Size (W x H x T): 1024 x 576 x 56 mm
- Pixels: 320 × 180 Dots
- Material: Die casting aluminum
- Weight: 15 Kg
- Brightness: 800 nits
- Processing depth: 14 bit
- Display refresh rate: 3840 Hz
- Color Temperature: 3200 ~ 9300 k
- Viewing angle (H): 140 deg
- Viewing angle (V): 140 deg
- Drive type: 1/30 Scan
- Pixel Pitch: 1.68, 2.0, 2.66, 3.2
- LED Type: SMD2020
- Module Size (W x H): 256 x 288 mm
- Pixel Per Module: 80 x 90 Dots
- Module Weight: 0.5 Kg
- AC Operating Voltage: 100 ~ 240
- AC Input Frequency: 50 / 60 hz
- Power Consumption (Max./Avg.): 460 / 153 W/m²
- Storage Temperature: -40 ~ +60 °C
- Operating Temperature: -10 ~ +40 °C
- Storage Humidity: 10% ~ 90% RH
- Operating Humidity: 10% ~ 90% RH
- IP Rating (Front/Rear): IP30 / IP30
- Pixel Pitch (mm): 2.0
- Pixel (dot): 512 × 288
- Size (W x H x T): 1024 x 576 x 56 mm
- Pixels: 320 × 180 Dots
- Material: Die casting aluminum
- Weight: 15 Kg
- Brightness: 800 nits
- Processing depth: 14 bit
- Display refresh rate: 3840 Hz
- Color Temperature: 3200 ~ 9300 k
- Viewing angle (H): 140 deg
- Viewing angle (V): 140 deg
- Drive type: 1/30 Scan
- Pixel Pitch: 1.68, 2.0, 2.66, 3.2
- LED Type: SMD2020
- Module Size (W x H): 256 x 288 mm
- Pixel Per Module: 80 x 90 Dots
- Module Weight: 0.5 Kg
- AC Operating Voltage: 100 ~ 240
- AC Input Frequency: 50 / 60 hz
- Power Consumption (Max./Avg.): 460 / 153 W/m²
- Storage Temperature: -40 ~ +60 °C
- Operating Temperature: -10 ~ +40 °C
- Storage Humidity: 10% ~ 90% RH
- Operating Humidity: 10% ~ 90% RH
- IP Rating (Front/Rear): IP30 / IP30
- Pixel Pitch (mm): 2.66
- Pixel (dot): 384 × 216
- Size (W x H x T): 1024 x 576 x 56 mm
- Pixels: 320 × 180 Dots
- Material: Die casting aluminum
- Weight: 15 Kg
- Brightness: 800 nits
- Processing depth: 14 bit
- Display refresh rate: 3840 Hz
- Color Temperature: 3200 ~ 9300 k
- Viewing angle (H): 140 deg
- Viewing angle (V): 140 deg
- Drive type: 1/30 Scan
- Pixel Pitch: 1.68, 2.0, 2.66, 3.2
- LED Type: SMD2020
- Module Size (W x H): 256 x 288 mm
- Pixel Per Module: 80 x 90 Dots
- Module Weight: 0.5 Kg
- AC Operating Voltage: 100 ~ 240
- AC Input Frequency: 50 / 60 hz
- Power Consumption (Max./Avg.): 460 / 153 W/m²
- Storage Temperature: -40 ~ +60 °C
- Operating Temperature: -10 ~ +40 °C
- Storage Humidity: 10% ~ 90% RH
- Operating Humidity: 10% ~ 90% RH
- IP Rating (Front/Rear): IP30 / IP30
- Pixel Pitch (mm): 3.2
- Pixel (dot): 320 × 180
- Size (W x H x T): 1024 x 576 x 56 mm
- Pixels: 320 × 180 Dots
- Material: Die casting aluminum
- Weight: 15 Kg
- Brightness: 800 nits
- Processing depth: 14 bit
- Display refresh rate: 3840 Hz
- Color Temperature: 3200 ~ 9300 k
- Viewing angle (H): 140 deg
- Viewing angle (V): 140 deg
- Drive type: 1/30 Scan
- Pixel Pitch: 1.68, 2.0, 2.66, 3.2
- LED Type: SMD2020
- Module Size (W x H): 256 x 288 mm
- Pixel Per Module: 80 x 90 Dots
- Module Weight: 0.5 Kg
- AC Operating Voltage: 100 ~ 240
- AC Input Frequency: 50 / 60 hz
- Power Consumption (Max./Avg.): 460 / 153 W/m²
- Storage Temperature: -40 ~ +60 °C
- Operating Temperature: -10 ~ +40 °C
- Storage Humidity: 10% ~ 90% RH
- Operating Humidity: 10% ~ 90% RH
- IP Rating (Front/Rear): IP30 / IP30
Download our full product specification brochure
Complete the form to download our spec sheet and get full details about this product
Ready to start a conversation?
Speak with our team about digital signage, CMS software, or retail media infrastructure. We’ll help you scope, design, and deploy the right solution.
Gallery
Testimonials
"onQ's team went above and beyond for our first and flagship Australian 1R club. Our signs look incredible and feature heavily on social media - almost every Instagram post we see incorporates these. We are forever grateful to the team for suggesting we instal their transparent LED, and more so for proposing that we supersize this. Beyond the signs, what has impressed us the most is the team. onQ respond to our queries, however big or small, within minutes - even to this day (months after the project has completed). Communication is exceptional. The team is exceptional. We look forward to working with them for years to come."
Amanada Mclean
CEO, 1Rebel Australia
The outcome exceeded expectations and we could not have hoped for a better result. Over and above the fact that our screen looks fantastic, I would like to commend your team on the excellent work and timely manner in which you completed the installation.
Director
Biggin & Scott
"Myles and the OnQ Digital team have been key partners for Bunnings, supporting the launch of our retail media network, Hammer Media. The team delivered our initial screens roll out of 300 screens in 150 Warehouses, on schedule and to budget; their expertise and responsiveness made it a seamless process with minimal impact on store operations. We look forward to working with them as we continue to grow.
James Rogers
Retail Media Product Manager, Bunnings Group
David Jones has been working with onQ for over five years and more recently partnering with onQ on our Retail Media Strategy, with the launch of David Jones Amplify. Myles and the onQ team have been very strategic, responsive, flexible and resourceful in providing solutions for our Retail Media Strategy. I personally have found onQ a fantastic partner, providing excellent pricing and diligent service to all of the key teams at David Jones. I would highly recommend onQ as a partner for any instore digital solution.
James Hollerman
Chief Marketing Officer, David Jones
I would like to extend my appreciation to you and your team regarding the professionalism and overall workmanship displayed during the installation of our screens at Grand Prix Mazda Aspley. I truly believe these screens have provided an added dynamic to both our New Car Showroom and Service Reception areas. I have no hesitation in recommending enQ Digital Group to anybody requiring such services
Luke Camilleri
Dealer Principal, Mazda Australia
MMAL has been working with onQ Digital since early 2023 on the rollout of interactive screens and video walls in our national dealer network. During this time, we have always found onQ to be highly professional and responsive to deal with. onQ consistently meets delivery and installation targets within budget. I can highly recommend onQ Digital as a digital solutions provider.
Vince Lombardo
Manager National Franchise Operations Network Strategy & Operations, Mitsubishi Motors Australia Limited
onQ is a leading technology company to work with, having assisted us in getting our store network onto their digital management platform and a rollout of new digital screens across our business. Their elevated service continues to exceed our expectations, along with always catering to our business needs. All experiences with their friendly team are easy, and enjoyable. Recent times have amplified how powerful digital technology is, allowing our business to be super reactive - thanks for the support onQ!
Mathew Kouvas
POLITIX Marketing Specialist, Country Road Group
The onQ team have been exceptional to work with. Their expertise in retail digital signage and their ability to deliver a consistent, high-quality installation across our national network has been outstanding.
Retail Operations Manager
Witchery
Who's this for?
Fashion & Apparel Retailers
Transform your retail floor with Q Series LED panels that deliver vibrant, seamless visuals for brand campaigns, seasonal promotions, and product storytelling.
Luxury & Premium Brand Flagships
Create a premium retail environment with Q Series LED walls that command attention and reinforce brand positioning through stunning visual quality.
Shopping Centre Operators
Deploy Q Series LED signage in anchor tenant spaces, food courts, and common areas to deliver high-impact advertising and wayfinding content.
Automotive Dealerships
Showcase vehicle campaigns and lifestyle content on Q Series LED panels that create an immersive, aspirational showroom environment.
Electronics & Appliance Retailers
Demonstrate product capabilities and run brand campaigns on Q Series LED displays that deliver the visual quality your technology products deserve.
Sports & Lifestyle Retailers
Energise your retail environment with Q Series LED displays that deliver dynamic sports content, brand campaigns, and promotional messaging at scale.
Frequesntly Asked Questions
The Q Series offers pixel pitches ranging from P2 to P4, optimised for retail lighting conditions to deliver clear, vibrant LED signage. These options provide a cost-effective solution for both single-store and multi-site digital signage deployments, ensuring high-quality visuals tailored to various retail environments.
Absolutely. The Q Series is designed for multi-site retail deployments and works natively with onQ CMS to provide centralised management of digital signage networks. This enables efficient scheduling, campaign management, and content updates across all stores from a single platform, supporting effective retail media strategies.
The Q Series integrates seamlessly with onQ CMS, allowing retailers to update promotional content, pricing, and seasonal campaigns in real time across all locations. This centralised control eliminates the need for on-site adjustments, ensuring consistent messaging on digital signage and LED signage throughout multi-site retail networks.
The QH Series is onQ Digital’s premium indoor LED video wall system featuring an independent cabinet frame for precise panel alignment, ideal for flagship and high-end venues. In contrast, the Q Series is optimised for cost-effective multi-site retail deployments, offering pixel pitches from P2 to P4 suited to large-scale retail media networks.
